KNIFE VALVES
RT-KGV SERIES
RT-KGV slurry knife valves are designed to ensure reliable flow control in severe abrasive and corrosive conditions, ensuring a long service life no matter how severe the operational conditions.

The unique design allows an affordable solution that can be easily maintained.
— Hard rock production
— Alumina and bauxites
— Coal
— Kaolin
APPLICATIONS
— Mineral sands
— Phosphates
— Pulp and paper
— Sand and gravel
— Sodium carbonate
— Cement
FEATURES
DIMENSIONS
Dimension range:
DN 50 (2") to DN 600 (24")

Maximum operating pressure:
DN 50 (2") to DN 400 (16") - 1034 kPa (150 psi)
DN 450 (18") to DN 600 (24") - 700 kPa (100 psi)

Flange connections:
DN 50 (2") to DN 600 (24"): as per ANSI B16.5 class 150

Materials:
— Casing: malleable cast iron, standard scope
— Disk: stainless steel 304 or 316, standard scope
— Seats: natural rubber, standard scope. EPDM and PTFE are also available

Drive options:
— Bevel gear
— Pneumatic cylinders
— Hydraulic cylinders
— Flywheel
— Motor
